XEBEC Back Burr Cutter Specifications
AlTiCrN Coated
[Short / Regular Type]
Product Code |
Cutter Radius |
Cutter Diameter øDc |
Neck Diameter ødn |
Neck Length |
Overall |
Shank Diameter |
Number of Blades |
||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XC-08-AS-3F |
0.4 |
0.8 |
0.48 |
3 |
60 |
3 |
3 |
|||||||||||
XC-13-AS-3F |
0.65 |
1.3 |
0.78 |
5 |
60 |
3 |
3 |
||||||||||||
XC-18-AS-3F |
0.9 |
1.8 |
1.1 |
6 |
60 |
3 |
3 |
||||||||||||
XC-23-AS-3F |
1.15 |
2.3 |
1.4 |
7.5 |
70 |
3 |
3 |
||||||||||||
XC-28-AS-3F |
1.4 |
2.8 |
1.7 |
9 |
70 |
4 |
3 |
||||||||||||
XC-33-AS-3F |
1.65 |
3.3 |
2.0 |
10.5 |
70 |
4 |
3 |
||||||||||||
XC-38-AS-3F |
1.9 |
3.8 |
2.4 |
12 |
70 |
4 |
3 |
||||||||||||
XC-48-AS-3F |
2.4 |
4.8 |
3.0 |
15 |
70 |
6 |
3 |
||||||||||||
XC-58-AS-3F |
2.9 |
5.8 |
3.5 |
18 |
70 |
6 |
3 |
||||||||||||
XC-78-AS-3F |
3.9 |
7.8 |
4.7 |
24 |
100 |
8 |
3 |
||||||||||||
XC-98-AS-3F |
4.9 |
9.8 |
5.9 |
30 |
120 |
10 |
3 |
Product Code |
Cutter Radius |
Cutter Diameter øDc |
Neck Diameter ødn |
Neck Length |
Overall |
Shank Diameter |
Number of Blades |
||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XC-08-A |
0.4 |
0.8 |
0.48 |
5 |
60 |
3 |
2 |
|||||||||||
XC-13-A |
0.65 |
1.3 |
0.78 |
8 |
60 |
3 |
2 |
||||||||||||
XC-18-A |
0.9 |
1.8 |
1.1 |
10 |
60 |
3 |
2 |
||||||||||||
XC-23-A |
1.15 |
2.3 |
1.4 |
12.5 |
70 |
3 |
2 |
||||||||||||
XC-28-A |
1.4 |
2.8 |
1.7 |
15 |
70 |
4 |
2 |
||||||||||||
XC-33-A |
1.65 |
3.3 |
2.0 |
17.5 |
70 |
4 |
2 |
||||||||||||
XC-38-A |
1.9 |
3.8 |
2.4 |
20 |
70 |
4 |
2 |
||||||||||||
XC-48-A |
2.4 |
4.8 |
3.0 |
25 |
70 |
6 |
2 |
||||||||||||
XC-58-A |
2.9 |
5.8 |
3.5 |
30 |
70 |
6 |
2 |
||||||||||||
XC-78-A |
3.9 |
7.8 |
4.7 |
40 |
100 |
8 |
3 |
||||||||||||
XC-98-A |
4.9 |
9.8 |
5.9 |
50 |
120 |
10 |
3 |
AlTiCrN Coated
[Straight Type]
Product Code |
Cutter Radius |
Cutter Diameter øDc |
Neck Diameter ødn |
Neck Length |
Overall |
Shank Diameter |
Number of Blades |
||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XC-18-B |
0.9 |
1.8 |
1.1 |
- |
50 |
1.1 |
2 |
|||||||||
XC-23-B |
1.15 |
2.3 |
1.4 |
- |
60 |
1.4 |
2 |
||||||||||
XC-28-B |
1.4 |
2.8 |
1.7 |
- |
70 |
1.7 |
2 |
||||||||||
XC-33-B |
1.65 |
3.3 |
2.0 |
- |
80 |
2.0 |
2 |
||||||||||
XC-38-B |
1.9 |
3.8 |
2.4 |
- |
85 |
2.4 |
2 |
||||||||||
XC-48-B |
2.4 |
4.8 |
3.0 |
- |
105 |
3.0 |
2 |
||||||||||
XC-58-B |
2.9 |
5.8 |
3.5 |
- |
120 |
3.5 |
2 |
||||||||||
XC-78-B |
3.9 |
7.8 |
4.7 |
- |
150 |
4.7 |
3 |
||||||||||
XC-98-B |
4.9 |
9.8 |
5.9 |
- |
180 |
5.9 |
3 |
Uncoated
[Regular Type]
Product Code |
Cutter Radius |
Cutter Diameter øDc |
Neck Diameter ødn |
Neck Length |
Overall |
Shank Diameter |
Number of Blades |
||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XC-08-A-N |
0.4 |
0.8 |
0.48 |
5 |
60 |
3 |
2 |
|||||||||||
XC-13-A-N |
0.65 |
1.3 |
0.78 |
8 |
60 |
3 |
2 |
||||||||||||
XC-18-A-N |
0.9 |
1.8 |
1.1 |
10 |
60 |
3 |
2 |
||||||||||||
XC-23-A-N |
1.15 |
2.3 |
1.4 |
12.5 |
70 |
3 |
2 |
||||||||||||
XC-28-A-N |
1.4 |
2.8 |
1.7 |
15 |
70 |
4 |
2 |
||||||||||||
XC-33-A-N |
1.65 |
3.3 |
2.0 |
17.5 |
70 |
4 |
2 |
||||||||||||
XC-38-A-N |
1.9 |
3.8 |
2.4 |
20 |
70 |
4 |
2 |
||||||||||||
XC-48-A-N |
2.4 |
4.8 |
3.0 |
25 |
70 |
6 |
2 |
||||||||||||
XC-58-A-N |
2.9 |
5.8 |
3.5 |
30 |
70 |
6 |
2 |
||||||||||||
XC-78-A-N |
3.9 |
7.8 |
4.7 |
40 |
100 |
8 |
3 |
||||||||||||
XC-98-A-N |
4.9 |
9.8 |
5.9 |
50 |
120 |
10 |
3 |
